Jumbo Bag Powder Packing Machine

VIDEO

Introduction

Ton Bag powder packing machine is big heavy equipment used for packing and weighing tons of materials, it is composed by electronic weighing, automatic bags taking off, dust removing. It’s with high degree of automation, packaging and high precision. Packing speed of super bag powder packing machine can be adjusted, superb structure; unique hydraulic lifting system make it easy to deal with ton bags and convenient to handle the latter procedure. Ton Bag packing machine are suitable for materials of mineral, chemical, building, and food as well as feed industry.

Main structure:

The ton bag powder package machine including pneumatic hook system, inflatable air sector, feed metering control mechanism, hydraulic elevator, roller conveyor and electrical control.

Application:

1. Food industry: like flour, milk powder, ground coffee powder etc.
2. Poultry feed: dog food, bird food, fish food.
3. Fertilizer, in powder.
4. Construction industry, like cement, adhesive mortar, putty, sand etc
5. Chemical industry: carbon black, pigment. PTA, polyester chips etc.

Features:

1. Jumbo bag powder packaging machine is designed according to powder material characteristics and customer requirements, advanced technology, durable structure and less wearing parts are needed.
2. Super bag powder packing machines can feed material and pack bags at variable speed, with stable performance and high precision.
3. Programmable electronic control system makes the control process reliable.
4. Advanced dust removing design, reduce dust pollution of working environment.
5. Weighing system uses electronic scale, set by a comprehensive panel digital calibration and parameter setting, with a total weight display and automatic peeled, auto zero, auto-correction features such as drop, high sensitivity and anti-interference ability.
6. Instrument is equipped with communication interfaces for online networking; the packaging machine can be real-time monitored and network managed.
7. There is detecting device in system.
8. Processes function of automatic modifying drop height.
9. Processes function of self-test, error pilot and fault code indication.
10. With the serial interfere to communicate the computer.
11. With five-figure password to control the accumulator in system.
12. Pre-set filling number in system.

Working flow of ton bag packing machine:

Before packing, the operator hang the 4 slings of the packing bag on the 4 lifting hooks and then cover the feeding opening of the powder packing machine on the sealed feeding cylinder. Then the operator starts the bag-clamping device to clamp the bag on the feeding pipe. Then, the blowing fan will blow air into bag for reshaping, and then start the feeding switch so that the packing machine will automatically go to working procedure (meanwhile the dust collection device begins to work): feeding at high or medium speed (at this time the vibrating device on the track truck is tamping the materials) —— feeding at slow speed —— stop feeding when rated weight is reached, then fall on the track truck —— be conveyed to the destination and the machine stops automatically —— be transported by the forklift or travelling crane.

Technical parameters:
